High Clearance Paddy Field Tracked Carrier

High Clearance Tracked Carrier for Paddy Fields & Wet Farmland – Efficient All-Terrain Transport Solution

Contact Us

PARAMETER


MODEL
7TY-500G
RATED LOAD CAPACITY
500 kg
L*W*H
2400*1450*1300 mm
FORWARD SPEED
4.8-60 m/min
ENGINE MODEL
Gasoline 168
REVERSE SPEED
4-16 mmin
RATED POWER
3.8 KW
HEIGHT ADJUSTMENT
700 800/900 mm
SPEED
1800 RPM
TRACK SPECIFICATIONS
130 x 72 x 51 mm
ADJUSTABLE PLATFORM DIMENSIONS
1550*1450*2250 mm
TRACK MATERIAL
Rubber
LOAD-BEARING
Steel, 5*150 mm
ADJUSTABLE TRACK SPACING
900-1700 mm
GEARS
Six Forward, Two Reverse
TUMING RADIUS
1700 mm
TOTAL WEIGHT
507 kg
RIVE TYPE
Self-Propelled
The High Clearance Tracked Carrier is a specially designed, high-efficiency transport vehicle for farmland operations. Its unique crawler track system with elevated ground clearance ensures stable performance across challenging terrains, including muddy fields, wet paddy fields, slippery slopes, and soft soil—greatly improving agricultural productivity.
Key features include:
  • High payload capacity for heavy loads in demanding conditions
  • Low ground pressure and excellent traction to prevent sinking in mud or waterlogged areas
  • Energy-efficient operation with low fuel consumption
  • User-friendly controls for easy handling, even for non-professional operators
This powerful assistant is ideal for modern farming, orchard transport, greenhouse logistics, and wetland harvesting—delivering reliability, durability, and superior performance in today's smart agriculture.
